EchoSmart, Real Time Liquid Level Gauge
EchoSmart
Deep-range, accurate, automatic, real time, continuous liquid level gaug, by Hizon
Over 7,000 sets field deployed.
About 3,000 wells under our IoT platform management
Features of EchoSmart:
High-End Engineering
EchoSmart is designed by our engineering team which has tons of systematic training and experience on critical systems. This is why EchoSmart is robust and reliable, compared to general industrial products.
Top-Of-The-Line Components
EchoSmart is made of top-of-the-line components in the market. If there is none available in the market, our engineering will customize one themselves. This ensures EchoSmart components have outstanding performance and reliability.
Extremely Robust
EchoSmart is engineered as a complete system for maximum robustness. Built on 16+ years of field-driven iteration and validated by rigorous manufacturing tests, it thrives in the harshest oilfield conditions.
Works In Anywhere, Any Weather, Any Time
EchoSmart delivers liquid level data in any weather, at any location, at any time — with no onsite personnel required. With built-in cellular and SCADA connectivity, it provides continuous remote insight while operating reliably in the harshest field conditions.
Accurate
Using our proprietary calibration system, EchoSmart delivers repeatable accuracy of ±10 feet at depths up to 13,000 feet.
Deep Range
EchoSmart can detect liquid level at the depth of 13,000 ft, due to the technologies used in it, including advanced components and signal processing technique.
Still operate with 0 casing pressure
It is easy for EchoSmart to get liquid level at about 13,000 feet deep with casing pressure. It can easily get liquid level at 9,000 feet deep with 0 casing pressure.
EchoSmart G1 installed onto Christmas tree
EchoSmart G1 Specification
EchoSmart G1¹ Specification
Name | Description |
|---|---|
Measurement depth （ft） | 13,000 |
Repeatability | better than ±10 feet |
Pressure rating (psi) | 1,470 |
Casing pressure rating (psi) | 1,470 |
Temperature rating (°F) | -40 to 160 |
Power supply | 120VAC / 60Hz |
Ex Certification² | ExdIIBT4 |
Ingress Protection rating | IP65 |
Communication | 4G |
Communication port | RS 485 |
Communication protocol | Modbus |
Dimension (in) | 16 x 12 x 8 |
¹. EchoSmart is a series of real time liquid level gauge by Hizon, we have models for other applications such as liquid level detection of high pressure gas wells, models for high concentration of H₂S. Please contact us if need liquid level gauge for such applications, or applications not mentioned here. We may have them in place already.
². EchoSmart carries existing Ex certificate, equivalent to NEC Class 1, Division 1
